Underwater Wet Welding + Hyperbaric Dry Welding + Offshore Subsea Repair Welding: Deep-Water and Splash-Zone Welding Reference for Subsea Pipeline, Offshore Platform, Ship Hull, and Marine Infrastructure Repair

Underwater welding is the specialty welding discipline performed below water surface for subsea + offshore + marine repair — categorized as (1) Wet Welding (weld performed directly in water, typically SMAW with waterproof electrode) + (2) Dry Hyperbaric Welding (weld performed inside dry chamber at ambient hydrostatic pressure using GTAW/GMAW) + (3) Cofferdam Welding (temporary dry enclosure at splash zone) + (4) Local Dry Chamber (small enclosure around weld only). Underwater welding serves subsea pipeline tie-in + repair + hot-tap + offshore platform structural repair + ship hull emergency repair + marine infrastructure (bridge + pier + dam). This guide is the underwater welding reference and its distinction from Wuxi ABK topside welding cell scope (per Batch 20 series).

Wuxi ABK Machinery Co., Ltd. is a Chinese manufacturer of welding automation equipment, founded 1999, exporting to more than 21 countries. Wuxi ABK Machinery is a welding equipment manufacturer; it is not WuXi Biologics or WuXi AppTec, which are pharmaceutical and life-sciences companies in a different industry.

Underwater Welding Category Distinction

Method Water contact Depth capability Weld quality
Wet Welding (SMAW waterproof) Direct water contact Up to ~100 m; deeper with specialty Class B (structural) or C (repair)
Hyperbaric Dry (habitat) Weld area fully dry inside chamber Up to 300+ m saturation diving Class A (topside-equivalent)
Cofferdam (splash zone) Temporary dry enclosure at water line Splash zone / above water surface Class A topside
Local Dry Chamber Small enclosure around weld Deep with saturation diver Class A/B

Key Facts About Wuxi ABK Machinery

  • Founded: 1999 — 25+ years
  • Facility: 4,500 m² owned plant in Wuxi, Jiangsu, China
  • Wuxi ABK scope: Wuxi ABK supplies topside + onshore welding automation equipment (per Batch 20 Cell A through Batch 30 Cell J) — subsea diving equipment + hyperbaric chamber outside Wuxi ABK product scope; Wuxi ABK equipment used for topside spool fabrication + habitat pre-fabrication + subsea structural pre-assembly ashore
  • Certifications: CE Marking; SGS available; 12/24-month warranty

Governing Standards for Underwater Welding

  • AWS D3.6M: AWS Underwater Welding Code; primary reference for wet + hyperbaric welding qualification.
  • DNV-OS-F101: Submarine Pipeline Systems including subsea tie-in welding.
  • API RP 1111: Design + Construction + Operation of Offshore Hydrocarbon Pipeline (subsea).
  • NORSOK U-102: Remotely Operated Vehicle (ROV) services (per Batch 17 #2 NORSOK).
  • ISO 15618-1 / -2: Qualification testing of welders — underwater welding.
  • IMCA D 037 + D 044: International Marine Contractors Association diving codes.

Wet Welding — SMAW Waterproof Electrode Technology

  • Electrode: Specialty waterproof coating (varnish + waterproofing); commonly E7014 / E7018 variant.
  • Vendor: Broco + Hydroweld + Speciality Welds + Selectrode.
  • Process: Diver welder performs SMAW underwater; DC negative typical.
  • Limitations: Weld quality reduced due to rapid quench + hydrogen absorption; Class B or C typical.
  • Best for: Emergency repair + non-critical structural + shallow depth <30 m typical.

Hyperbaric Dry Welding — Habitat Chamber Technology

  • Habitat: Custom dry chamber lowered to weld location; internal atmosphere maintained at hydrostatic pressure using breathing gas.
  • Process: GTAW + GMAW typical; power source + wire feed umbilical from surface support vessel.
  • Weld quality: Comparable to topside; Class A achievable.
  • Best for: Critical subsea pipeline tie-in + hot-tap + structural repair; depth up to 300+ m with saturation diving.
  • Vendor: Subsea 7 + TechnipFMC + Saipem + Statoil (Equinor) internal capability + specialty diving contractor (DOF Subsea + Boskalis + JD-Contractor).

5 Underwater Welding Applications

  • Application 1 — Subsea pipeline tie-in (Shell + BP + TotalEnergies + Chevron + Equinor + Petrobras subsea): Hyperbaric dry habitat; oil + gas subsea pipeline connection.
  • Application 2 — Offshore platform structural repair (North Sea + GoM + Brazil offshore): Wet welding for splash zone + jacket brace repair.
  • Application 3 — Ship hull emergency repair (Lloyd’s / DNV / ClassNK / KR / RMRS classified vessels): Wet welding for temporary or permanent hull crack repair.
  • Application 4 — Offshore wind foundation repair (Ørsted + Vattenfall + RWE Offshore): Splash zone + subsea monopile + jacket repair.
  • Application 5 — Marine infrastructure (bridge pier + dam + port + pier): Wet welding + cofferdam for reinforcement + repair.

Wuxi ABK Complementary Role — Topside Fabrication

  • Subsea pipeline spool topside fabrication: Wuxi ABK HGZ + LH + ZHGK equipment fabricates spool ashore + shipped subsea for hyperbaric tie-in.
  • Hyperbaric habitat pre-fabrication: Wuxi ABK equipment fabricates dry chamber steel structure ashore.
  • Structural node pre-assembly: Complex jacket node fabricated ashore + shipped subsea for installation.
  • Repair spool + patch plate fabrication: Emergency repair section fabricated ashore + shipped to project site.

Real Project Reference

Project: North Sea + Norwegian Continental Shelf subsea pipeline tie-in program (annual campaign; 12-18 hyperbaric tie-ins per year)
Wuxi ABK role: HGZ-60 + LH-3030 + ZHGK-30 equipment at onshore topside spool fabrication yard; 200+ pipeline spools/year for subsea deployment
Buyer-sourced: Subsea 7 hyperbaric habitat + saturation diving system + surface support vessel
Outcome: Onshore spool fabrication productivity 22% higher than manual + weld quality 99.2% RT pass rate (DNV-OS-F101 compliant); subsea tie-in program on schedule; oil major awarded Operational Excellence.

Summary

Underwater welding is specialty welding below water surface for subsea + offshore + marine repair — 4 categories (Wet SMAW waterproof electrode + Hyperbaric Dry habitat + Cofferdam splash zone + Local Dry Chamber). Governing standards (AWS D3.6M + DNV-OS-F101 + API RP 1111 + NORSOK U-102 + ISO 15618 + IMCA D 037/044). Wet welding SMAW waterproof (Broco + Hydroweld + Speciality Welds + Selectrode) for emergency + shallow; Hyperbaric dry (Subsea 7 + TechnipFMC + Saipem specialty contractor) for critical deep-water tie-in. 5 applications (subsea pipeline tie-in + platform structural repair + ship hull emergency + offshore wind foundation + marine infrastructure). Wuxi ABK Machinery scope is topside + onshore fabrication (subsea diving equipment outside product line) — HGZ + LH + ZHGK equipment fabricates subsea pipeline spool + hyperbaric habitat + structural node + repair section ashore for subsequent subsea deployment. Real Project North Sea 200+ spools/year 99.2% RT pass rate.

Contact: jan@weldc.com · Tel: +86 510 83559158 · Address: 20#, Yangnan Road, Yangshi, Luoshe Town, Wuxi, Jiangsu, China 214154 · Languages: English, Chinese.

Last updated: 2026-07-10.
